Inkjet printing media | P-GB002
Application : Signage, digital printing ,screen printing for banner and outdoor, indoor digital printing for media inkjet .
elf Adhesive Vinyl (data sheet )：
Specification : 0.08mm x 120gsm
Specification | Description | |
PVC | Type | Calendered monomeric soft PVC film |
Thickness | 80±10um | |
Color Code | Ceramic white | |
Shrinkage | ≦0.8% | |
Surface Tension | ≧30dn/cm | |
Opacity | >80% | |
Adhesive | Type | Clear solvent based permanent pressure sensitive glue |
Weight(g/㎡) | 18±2 | |
Adhesion Temperature | 15℃~40℃ | |
180° Peeling Force | ≧7N/25mm （GB2792-81China National Standard） | |
Initial Adhesion-Ball Tack | ≧5#Steel Ball （GB4852-84 China National Standard） | |
Holding Power | ≧800min （GB4854-84 China National Standard ） | |
Liner | Type | Kraft paper |
Color | white | |
Weight | 120g±5g/㎡ | |
Release Force | 0.4~1N/4cm | |
Storage Period | 12 months under ordinary condition at temperature of 22℃ and relative humidity of 50-55% | |
Application | Outdoor digital and silk screen printing media for signage display and vehicle graphics applications | |
Compatibility of printers and ink | Media is suitable for all solvent and eco solvent digital printers with heating system including Phaeton,Infiniti, Mimaki , Roland, Vutek and HP Scitex. Inks should be the original ink from the printer manufacturers. The best printing temperature is 38-43℃. | |
Specification : 0.10mm x 140gsm
Specification | Description | |
PVC | Type | Calendered monomeric soft PVC film |
Thickness | 100±10um | |
Color Code | Ceramic white | |
Shrinkage | ≦0.8% | |
Surface Tension | ≧30dn/cm | |
Opacity | >80% | |
Adhesive | Type | Clear solvent based permanent pressure sensitive glue |
Weight(g/㎡) | 22±2 | |
Adhesion Temperature | 15℃~40℃ | |
180° Peeling Force | ≧7N/25mm （GB2792-81 China National Standard） | |
Initial Adhesion-Ball Tack | ≧5#Steel Ball （GB4852-84 China National Standard） | |
Holding Power | ≧800min （GB4854-84 China National Standard ） | |
Liner | Type | Kraft paper |
Color | white | |
Weight | 140g±5g/㎡ | |
Release Force | 0.4~1N/4cm | |
Storage Period | 12 months under ordinary condition at temperature of 22℃ and relative humidity of 50-55% | |
Application | Outdoor digital and silk screen printing media for signage display and vehicle graphics applications | |
Compatibility of printers and ink | Media is suitable for all solvent and eco solvent digital printers with heating system including Phaeton,Infiniti, Mimaki , Roland, Vutek and HP Scitex. Inks should be the original ink from the printer manufacturers. The best printing temperature is 38-43℃. | |
One Way Vision
Product Description:
One Way Vision has showed its great advantage in the advertising market. It is made of a PVC vinyl substrate, with the anti-tractility PVC-coated material; our products optimize ink adhesion and color reproduction for long-lasting brilliant prints. Its good capability of anti-tractility prevents it from distortion and rupture. It allows stunning graphics on one side and clear, unobstructed view through the glass on the other. It can keep a transmittance at 50% also a colorful expression of picture.
Description: | One Way Vision Plastic Film For Advertising |
Surface Composition | Glossy,white and black,calendered monomeric PVC film |
Thickness of Film | 80mic |
Adhesive character: | clear,completely removable,acrylic pressure sensitive adhesive |
Paper liner type: | One-side silicone art paper |
Ink absorption: | Solvent, ECO solvent,Latex, UV |
Durability: | Up to 2 year |
Usage Range | -20ºC-80ºC |
shrinkage | <1% |
Size(Width and length) | 0.914/1.06/1.27/1.37/1.52*50 m |
Packing:
Size | Packing |
0.914 x 50m | Carton |
1.07 x 50m | Carton |
1.27 x 50m | Carton |
1.52 x 50m | Carton |
Application:
1. Great for vehicle advertisements on cars, buses, train, tram, etc.
2. Ideal for window advertisements on buildings, offices and shops etc.
3. Suitable for application onto transparent glass, acrylic, polycarbonate.
4. Excellent resistance to a wide range of physical and climatic conditions.
